Specifications
General
Series Name
500 Series
Color
Black
Manufacturer Color
Black
Fuel Type
Electric
Type
Built-In
Cooktop
Burners/Elements
4
Power Output
β’ Front Left: 1,700 / 700 W
β’ Back Left: 1,800 W
β’ Back Right: 1,200 W
β’ Front Right: 2,500 W
β’ Back Left: 1,800 W
β’ Back Right: 1,200 W
β’ Front Right: 2,500 W
Burner/Element Size
β’ Front Left Heating Element: 7"/5"
β’ Back Left Heating Element: 7"
β’ Back Right Heating Element: 6"
β’ Front Right Heating Element: 9"
β’ Back Left Heating Element: 7"
β’ Back Right Heating Element: 6"
β’ Front Right Heating Element: 9"
Elements
Smoothtop
Surface Features
Ceramic Glass
Features
Additional Information
β’ Cooktop Design Coordinates with Bosch Ovens and Ventilation
β’ 2-Level Heat Indicator - Warns if Cooktop is Warm or Hot
β’ Dual Element Offers the Capability to use Multiple Pan Sizes
β’ Infinite Temperature Controls for Precision Cooking
β’ Powerful 2,500W Right-Front Burner for Faster Boil Times
β’ 2-Level Heat Indicator - Warns if Cooktop is Warm or Hot
β’ Dual Element Offers the Capability to use Multiple Pan Sizes
β’ Infinite Temperature Controls for Precision Cooking
β’ Powerful 2,500W Right-Front Burner for Faster Boil Times
Electrical Information
Information
β’ 7,200 W
β’ 208 / 240 V
β’ 60 Hz
β’ 30 A
β’ 208 / 240 V
β’ 60 Hz
β’ 30 A
Certifications and Approvals
Sabbath Mode
No
Dimensions
Class Width
30"
Width
31.02 inch(es) / 78.8 cm
Height
4 inch(es) / 10.16 cm
Depth
21.26 inch(es) / 54.0 cm
Weight
25 lb(s) / 11.34 kg
Additional Dimensions
Required cutout size (HxWxD) (in) : 4" x 28 7/8" x 20".
Warranty
Warranty
Limited 1 year parts and labor
UPC
UPC#
825225907480
